產品介紹
PRODUCTINTRODuCTION
炬鼎LGA/×CP系列除氣機/除氣站由電機帶動浸入轉運包鋁水中的石墨轉子旋轉，同時向鋁水中導入高純氮?dú)?或氬氣)和精煉劑。鋁水與氮?dú)?、精煉劑在石墨轉子的旋轉作用下達到除氣、除渣和精煉的目的。
LGA /XCP series of degassing machine/station has a Graphite rotor im-mersed in molten aluminium driven by motor, Ilt introduce high purity ni-trogen (or argon) and refining agent to aluminum liquid at the same time.With the rotation of the graphite rotor,the molten aluminum,nitrogenand refining agent achieve the purpose of degassing, slag removal and re-fining.
產品特點
PRODUCT FEATURES
1、可有效去除鋁水中的有害氣體(主要是氫)和氧化物，兼具氣體精煉和熔劑精煉二者的長處。
2、金屬損耗少，采用合適的熔劑精煉后，溶體表面的浮渣量少且松散；極少發生包裹金屬的現象。拔渣時帶出的金屬量小。
3、具有防墜落機構、精煉劑料位檢測、氣路泄漏檢測等保護系統
4、專門的精煉劑送料機構，準確控制送料數量，供料均勻。
5、機架下設有行走輪，人工推動轉向輕便平穩，便于在多個除氣對象間轉移。
6、可完成多種工藝過程,熔劑配合、可完成調質、除氣、除渣等功能，效能好。設備采用全自動一體化控制，一鍵操作更便捷，顯著改善生產現場操作環境。
1.Can effectively remove harmful gases (mainly hydrogen) and oxides in alumi-num liquid, both gas refining and flux refining two advantages.
2.Less metal consumption. When the flux is refined, the amount of scum on thedissolution surface is little and loose.A small amount of metal is taken outduring the slag.
3.with anti falling mechanism, refining agent, material level detection, gas leak-age detection system.
4.Special designed refining agent feeding mechanism, precise control feedingquantity, uniform feeding.
5.There is a walking wheel under the frame, which is easy and easy to transferand easy to transfer between the air elimination objects.
6.Can complete a variety of process, flux matching, can complete the quenchingand tempering,degassing，slag removal and other functions,good perfor-mance.The equipment adopts automatic integration control, one key opera-tion is more convenient,and the operation environment of production site is im-proved remarkably.
